Peb Theem Roj Immersed Distribution Transformer
Lub transformer yog ib yam khoom zoo li qub, uas tsis ua haujlwm txhua yam. Tab sis lub luag haujlwm tseem ceeb yog nqis los thiab nce qib ntawm qhov ntsuas hluav taws xob. Invariably, thaum nce / nqis qhov voltage, nws kuj nce / nce tam sim no inversely.
Hauj lwm lawm
DKLINEPeb theem roj immersed faib transformer
Kev piav qhia
Peb-theem roj-immersed transformer siv hom tshiab rwb thaiv tsev qauv thiab txhim kho lub peev xwm ntawm luv luv-circuit resistance.
DKLINEPeb theem roj immersed faib transformer
TECHNICAL PARAMETERS
6 ~ 12 kV
|
Tus nqi muaj peev xwm |
Voltage ratio |
HV tapping ntau |
Load poob (w) |
Tsis muaj load poob (w) |
Tsis muaj load tam sim no (%) |
luv Circuit Court impedance |
|
|
HV (kV) |
LV (kV) |
||||||
|
25 |
6 6.3 10 11 |
0.4 0.415 0.433 |
5%,0 2x2.5%,0 |
115 |
550 |
2.3 |
3.5~4.5 |
|
50 |
170 |
910 |
2.0 |
||||
|
100 |
290 |
1580 |
1.8 |
||||
|
125 |
340 |
1890 |
1.7 |
||||
|
160 |
400 |
2310 |
1.6 |
||||
|
200 |
480 |
2730 |
1.5 |
||||
|
250 |
560 |
3200 |
1.4 |
||||
|
315 |
670 |
3830 |
1.4 |
||||
|
400 |
800 |
4520 |
1.3 |
||||
|
500 |
960 |
5410 |
1.2 |
||||
|
630 |
1200 |
6200 |
1.1 |
||||
|
800 |
1400 |
7500 |
1.0 |
||||
|
1000 |
1700 |
10300 |
1.0 |
||||
|
1250 |
1950 |
12000 |
0.9 |
||||
|
1600 |
2400 |
14500 |
0.8 |
||||
|
2000 |
2840 |
17200 |
0.5 |
||||
|
2500 |
3350 |
20300 |
0.4 |
||||
20 ~ 25 kV
|
Tus nqi muaj peev xwm |
Voltage ratio |
HV tapping ntau |
Load poob (w) |
Tsis muaj load poob (w) |
Tsis muaj load tam sim no (%) |
luv Circuit Court impedance |
|
|
HV (kV) |
LV (kV) |
||||||
|
25 |
20 22 24 25 |
0.4 0.415 0.433 |
5%,0 2x2.5%,0 |
80 |
600 |
2.3 |
4.5~6.0 |
|
50 |
130 |
1010 |
2.0 |
||||
|
100 |
200 |
1730 |
1.6 |
||||
|
125 |
240 |
2080 |
1.5 |
||||
|
160 |
290 |
2540 |
1.4 |
||||
|
200 |
340 |
3000 |
1.3 |
||||
|
250 |
400 |
3520 |
1.2 |
||||
|
315 |
480 |
4210 |
1.1 |
||||
|
400 |
570 |
4970 |
1.0 |
||||
|
500 |
680 |
5940 |
1.0 |
||||
|
630 |
810 |
6820 |
0.9 |
||||
|
800 |
980 |
8250 |
0.8 |
||||
|
1000 |
1150 |
11330 |
0.7 |
||||
|
1250 |
1380 |
13200 |
0.7 |
||||
|
1600 |
1160 |
15950 |
0.6 |
||||
|
2000 |
1850 |
19140 |
0.6 |
||||
|
2500 |
2320 |
22220 |
0.5 |
||||
30-36 kV
|
Tus nqi muaj peev xwm |
Voltage ratio |
HV tapping ntau |
Load poob (w) |
Tsis muaj load poob (w) |
Tsis muaj load tam sim no (%) |
luv Circuit Court impedance |
|
|
HV (kV) |
LV (kV) |
||||||
|
25 |
30 33 35 36 |
0.4 0.415 0.433 |
5%,0 2x2.5%,0 |
125 |
755 |
2.3 |
4.5~6.5 |
|
50 |
210 |
1270 |
2.0 |
||||
|
100 |
290 |
2120 |
1.8 |
||||
|
125 |
340 |
2500 |
1.7 |
||||
|
160 |
360 |
2970 |
1.6 |
||||
|
200 |
430 |
3500 |
1.5 |
||||
|
250 |
510 |
4160 |
1.4 |
||||
|
315 |
610 |
5010 |
1.4 |
||||
|
400 |
730 |
6050 |
1.3 |
||||
|
500 |
860 |
7280 |
1.2 |
||||
|
630 |
1040 |
8280 |
1.1 |
||||
|
800 |
1230 |
9900 |
1.0 |
||||
|
1000 |
1440 |
12150 |
1.0 |
||||
|
1250 |
1760 |
14670 |
0.9 |
||||
|
1600 |
2120 |
17550 |
0.8 |
||||
|
2500 |
3150 |
23000 |
0.8 |
||||
DKLINEPeb theem roj immersed faib transformer
FAQ:
1. MOQ yog dab tsi?
Tsis muaj MOQ txwv hauv thawj qhov kev txiav txim, thiab 100pcs ntxiv.
2.EPC cov khoom tsim thiab muab ntau?
Yog lawm, peb tau muab cov khoom siv LV thiab MV EPC ntau xyoo.and muaj pab pawg tsim muaj zog.
3.OEM muaj?
Yog, peb tab tom muab lub thauj tog rau nkoj clamp raws li kev cai yuav tsum tau.
4.Ua tiav cov ntaub ntawv rau kev sib tw?
Yog, tag nrho cov ntaub ntawv npaj npaj xa tuaj.
DKLINEPeb theem roj immersed faib transformer
ADVANTAGE:
Tag nrho cov txheej txheem tswj xyuas kom paub meej tias qhov zoo;
ISO 9001, ISO 14001 thiab ISO 18001 yam;
Tsawg tus nqi qis.
Cov lus teb ceev ceev, ceev cov lus hais.
Dependably kev pab cuam tom qab muag.
Tag nrho cov ntaub ntawv xa mus rau kev sib tw.
