Ua Bolt

DKLINEUa bolt

Kev piav qhia

bolts yog hlau rods khoov rau hauv cov duab ntawm tsab ntawv "U" nrog cov ntsia hlau threads ntawm txhua qhov kawg. Cov threaded xaus yog tsim los fastened los ntawm kev ruaj ntseg ceev thiab ntxhua khaub ncaws; lawv kuj tuaj yeem siv nrog crosspiece / rooj zaum spanning ob leeg threaded kawg ntawm lub ntsia liaj qhov rooj kom nws ruaj ntseg dua nyob rau hauv tej chaw thiab siv.



DKLINEUa bolt

NTA

■ Corrosion resistant

■ Lub neej ntev





DKLINEUa bolt

TECHNICAL PARAMETERS

Khoom siv thiab kev tsim kho
Khoom siv	Kub-dip galvanizing

Lawv feem ntau yog ua los ntawm cov ntaub ntawv ruaj khov xws li cov pa roj carbon steel, cov hlau me me (feem ntau plated nrog zinc rau corrosion kuj), los yog corrosive kuj A2 / 304 los yog A4 / 316 stainless hlau.



DKLINEUa bolt

DIMENSION



SIZE	Sab hauv	Sab hauv qhov siab	Xov Length
M6 x 1/2"	24	42	22
M6 x 3/4"	30	47	22
M6 x 1"	38	53	25
M6 x 1 1/4"	46	64	28
M6 x 1 1/2"	52	73	30
M6 x 2"	64	85	32
M6 x 2 1/2"	78	105	35
M6 x 3"	92	118	35
M6 x 4"	118	150	55
M8 x 1/2"	24	42	22
M8 x 3/4"	30	47	22
M8 x 1"	38	53	25
M8 x 1 1/4"	46	64	28
M8 x 1 1/2"	52	73	30
M8 x 2"	64	85	32
M8 x 2 1/2"	78	105	35
M8 x 3"	92	118	35
M8 x 4"	118	150	55
M10 x 3/8"	18	35	22
M10 x 1/2"	24	42	25
M10 x 3/4"	30	47	25
M10 x 1"	38	60	30
M10 x 1 1/4"	46	66	32
M10 x 1 1/2"	52	73	35
M10 x 2"	64	85	35
M10 x 2 1/2"	78	105	35
M10 x 3"	92	118	35
M10 x 3 1/2"	105	130	50
M10 x 4"	118	157	55
M10 x 5"	144	175	65
M10 x 6"	174	210	65
M10 x 8"	224	260	75
M12 x 1 1/2"	52	73	30
M12 x 2"	64	85	32
M12 x 2 1/2"	78	110	35
M12 x 3"	92	118	50
M12 x 4"	118	150	55
M12 x 5"	144	175	65
M12 x 6"	174	210	65
M12 x 8"	224	260	75
M12 x 10"	278	320	80
M12 x 12"	332	380	90
M16 x 4"	118	157	65
M16 x 5"	144	175	65
M16 x 6"	174	210	65
M16 x 7"	196	240	65
M16 x 8"	224	260	75
M16 x 10"	278	320	80
M20 x 8"	224	260	75
M20 x 9"	247	290	80
M20 x 10"	280	320	80
M20 x 12"	332	370	100
M22 x 10"	278	320	80
M22 x 12"	332	370	100
M24 x 10"	278	320	80
M24 x 12"	332	370	100
M24 x 14"	362	403	100
M24 x 16"	414	454	100
M30 x 18"	466	516	110
M30 x 20"	518	570	110
M30 x 22"	568	621	110
M36 x 24"	620	678	130
M36 x 26"	670	729	120
M36 x 28"	722	765	110
M36 x 30"	774	815	110
M42 x 32"	826	870	110
M42 x 36"	926	970	110







DKLINEUa bolt

FAQ:

MOQ yog dab tsi?

Tsis muaj MOQ txwv hauv thawj qhov kev txiav txim, thiab 100pcs ntxiv.

Cov qauv muab?

Peb tab tom muab cov qauv pub dawb, tab sis xav tau them tus nqi thauj khoom.

EPC cov khoom tsim thiab muab ntau?

Yog lawm, peb tau muab cov khoom siv LV thiab MV EPC ntau xyoo.and muaj pab pawg tsim muaj zog.

OEM muaj?

Yog, peb tab tom muab lub thauj tog rau nkoj clamp raws li kev cai yuav tsum tau.

Ua kom tiav cov ntaub ntawv rau kev sib tw?

Yog, tag nrho cov ntaub ntawv npaj npaj xa tuaj.

DKLINEUa bolt

ADVANTAGE:

Tag nrho cov txheej txheem tswj xyuas kom paub meej tias qhov zoo;

ISO 9001, ISO 14001 thiab ISO 18001 yam;

Tsawg tus nqi qis.

Cov lus teb ceev ceev, ceev cov lus hais.

Dependably kev pab cuam tom qab muag.

Tag nrho cov ntaub ntawv xa mus rau kev sib tw.
